Send InquiryCAT 950GC 225 HP Wheel Loader
Product Details:
- Product Type Wheel Loader
- General Use Industrial
- Material Other
- Feature High Efficiency
- Warranty Yes
CAT 950GC 225 HP Wheel Loader Price And Quantity
- 5000000.00 - 15000000.00 INR/Unit
- 1 Unit
CAT 950GC 225 HP Wheel Loader Product Specifications
- Wheel Loader
- High Efficiency
- Yes
- Industrial
- Other
CAT 950GC 225 HP Wheel Loader Trade Information
- Cash Advance (CA)
- 1 Unit Per Week
- 30 Days
- All India
Product Description
Owing to our rich industry experience and knowledge of this domain; we have been able to manufacture an excellent quality CAT 950GC 225 HP Wheel Loader. We manufacture our offered range of loader vehicles using superior quality raw material and components that are sourced from the most trusted and reputed vendors of the market. Offered CAT 950GC 225 HP Wheel Loader is widely used in the construction of buildings, roads and factories.
Product details
|
Center Line of Rear Axle to Hitch |
1650 mm |
|
Crankcase |
20 L |
|
Dump Angle |
52 degree @maximum lift |
|
Height to Center Line of Axle |
750 mm |
|
Lift Arm Clearance |
3649 mm |
|
Maximum Operating Pressure |
27900 kPa @ 50 +/- 1.5 L/min |
|
Rack Back Angle |
60 degree @maximum lift |
|
Steering System Pump Type |
Piston |
|
Cooling Tank |
48 L |
|
Displacement |
7.01 L |
|
Transmission |
45 L |
|
Power |
151 kW (202 HP) @ 2,200 rpm (Net) |
|
Fuel Tank |
290 L |
|
Engine Model |
Cat C7.1 |
|
Max Pump Flow Rate |
248 L/min @ 2,200 rpm |
|
Turning Radius |
3419 mm (Outside of tyres),2745 mm (Inside of Tyres),6190 mm (Outside edge of counterweight) |
|
Ground Clearance |
460 mm |
|
Wheel Base |
655 mm |
|
Travelling Speed -Reverse |
7.0 / 12.5 / 22.0 km/h |
|
Travelling Speed -Forward |
7.0 / 12.5 / 22.0 / 34.0 km/h |
|
Max. Torque |
1020 Nm (Gross) @1400 rpm,931 Nm (Net) @1300 rpm |
|
Stroke |
135 mm |
|
Bore |
105 mm |
|
Gross Power |
168 kW (225 HP) @2200 rpm (Rated), 171 kW (229 HP) (Max) |
|
Loader Bucket Capacity |
2.5 m3 to 4.4 m3 |
|
Maximum Operating Weight |
18676 kg |
|
Model Name/Number |
950GC |
|
Brand |
CAT |
