Send InquiryCAT 966M 311 HP Wheel Loader
Product Details:
- Product Type Wheel Loader
- General Use Industrial
- Material Other
- Control System Manual
- Feature Low Energy Consumption
CAT 966M 311 HP Wheel Loader Price And Quantity
- 5000000.00 - 15000000.00 INR/Unit
- 1 Unit
CAT 966M 311 HP Wheel Loader Product Specifications
- Low Energy Consumption
- Wheel Loader
- Other
- Industrial
- Manual
CAT 966M 311 HP Wheel Loader Trade Information
- Cash Advance (CA)
- 1 Unit Per Week
- 30 Days
- All India
Product Description
Product details
|
Cooling System Capacity |
71.6 L |
|
Crankcase Capacity |
24.5 L |
|
Dump at Maximum Raise |
1.4 Sec. |
|
Hydraulic Tank Capacity |
125 L |
|
Implement Pump Type |
Variable displacement piston |
|
Maximum Operating Pressure |
31000 kPa |
|
Maximum Pump Output |
360 L/min |
|
Net Power |
206 kW / 276 HP at 1700 rpm |
|
Net Torque |
1527 N.m at 1000 rpm |
|
Peak Gross Torque |
1599 N.m at 1200 rpm |
|
Raise From Carry Position |
6.1 Sec. |
|
Static Tipping Load |
14668 kg (With Tire Deflection),15822 kg (No Tire Deflection) |
|
Transmission Gears |
4 forward,4 Reverse |
|
Rear Axle Oscillation |
+/-13 degrees |
|
Front Axle |
Fixed |
|
Breakout Force |
173 kN |
|
Displacement |
9.3 L |
|
Transmission |
58.5 L |
|
Fuel Tank |
313 L |
|
Engine Model |
Cat C9.3 ACERT |
|
Travelling Speed -Reverse |
7.1/14.4/25.9/40.0 km/h |
|
Travelling Speed -Forward |
6.5/13.0/23.5/40.0 km/h |
|
Stroke |
149 mm |
|
Bore |
115 mm |
|
Gross Power |
232 kW / 311 HP at 1800 rpm |
|
Loader Bucket Capacity |
2.5-9.2 m3 |
|
Maximum Operating Weight |
23220 kg |
|
Model Name/Number |
966M |
|
Brand |
CAT |
